| C102 (68 Pin, Gray) |
Engine - Engine room fuse block |
Engine room fuse block |
| C103 (68 Pin, White) |
Body - Engine room fuse block |
Engine room fuse block |
| C104 (8 Pin, Gray) |
Body - Engine room fuse block |
Engine room fuse block |
| C114 (36 Pin, Black) |
Engine Extension - Engine |
Behind engine room fuse block |
| C202 (23 Pin, White) |
IP - Body |
Connector box at the bottom of left A pillar |
| C203 (16 Pin, Yellow) |
IP - Body |
Connector box at the bottom of left A pillar |
| C207 (22 Pin, White) |
IP - TCM |
Behind driver's knee bolster |
| C216 (20 Pin, White) |
Engine - IP |
Near the Connector box at the bottom of right A pillar |
| G103 |
Engine |
Between engine room fuse block and battery |
| G106 |
Battery |
Front and center of engine cylinder block |
| G107 |
Battery |
Between engine room fuse block and battery |
| G202 |
IP |
Left bottom of IP center molding |
